Galvanized Steel Tubular Fence Stain Yellow Powder Interpon 80 microns thick 1820mm x 3000mm width

Product Categories
Top Fencing Co.Limited
Contact Now

Galvanized Steel Tubular Fence Stain Yellow Powder Interpon 80 microns thick 1820mm x 3000mm width

Brand Name : LN Garrison Fence

Model Number : Garrison-1200mm-1500mm-1800mm-2100mm-2400mm

Certification : AS/NZS1163& AS/NZS4506-1998

Place of Origin : New Zealand And Australia Design

MOQ : 100

Price : 9.88$

Payment Terms : TT 30% deposit balance 70% at sight of done cargo

Supply Ability : 10001

Delivery Time : 7 days

Packaging Details : Metal Pallet With Plastic Jacket

Materials : Q235

Color : Black and Grey or other

Dimensions : 1800mm x 2400mm ,2100mm x 2400mm or Customized

Salt Spray Testing : Pass

Treatment : Powder Coated ,Hot Dipped Galvanized

Technical : Punch Pipes and Welding etc

Nick Name : Steel Fence ,Steel Tubular Fence ,Steel Spear Fence,Garrison Fence,ornamental steel fence

Upright Pipes : 25mm x 25mm x 1.20mm

Rails : 40mm x 40mm x 1.60mm

Post : RHS60/65/70/80/100 length 2100mm-3000mm

Popular : Powder Coated Stain Black

Apllication : Garden Fence, Farm Fence, Residential Fence, Highway Fence, Railway Fence, Balcony Fence, Airport Fence, Stadium Fence, Municipal Fence, Bridge Fence, Stair Fence, Air-Condition Fence

Contact Now

Galvanized Steel Tubular Fence Stain Yellow Powder Interpon 80 microns thick 1820mm x 3000mm width

LN focus on supply tubular steel fence which all minimum coated 14 microns zinc thickness to guarantee the corrosion ability better than another fence you saw in the market, but this is not enough all tubular steel fencing coated INTERPON brand powder ANTI UV anti rusting the average service life of steel fencing are more than 10 years

Material: hot dipped galvanized steel pipe
Horizontal pipe(rail):32*32,40*40, 45*45, 50*50, 60*60mm
Vertical pipe(picket):16*16, 20*20, 25*25, 30*30mm
Post:40*40, 50*50, 60*60,80*80mm
Fence width:2.1m,2.4m,3m
Fence height:1.2m,1.5m,1.8m,2.0m,2.2m,etc
Surface treatment:hot dipped galvanized, powder coated


Specification

Product Name:

Powder Coated Zinc Steel Fence

Material:

Hot-dipped Galvanized Steel tube

A shape of a tube section

Square / Rectangle / Flat oval / Oval / Round / Groove / Club shape

Surface Treatment:

Hot dipped galvanized—Zinc Phosphate—Zinc rich epoxy Powder coating – Polyester Color Powder Coating

Zinc Steel fence Processing

Cut Shot—Punching Holes—Acid washing—Rich zinc Powder coating – Polyester Color Powder Coating—Assembly – Packing

Colour

Black, White, Coffee, Grey, Blue, Green etc ( according to customers require)

Feature:

Maintenance free, Rust-proof, solid structure, Eco-friendly

Installation mode

Assembling (without welding)

Accessory

Security bolt& nuts, Connector, Decorative part, Gasket, Cover for a post, Baseplate, Snap Spring

Packing:

Thin Film/Piece, Bubble Film/Unit inside, Woven Bag/Unit outside, Pallet.

Techniacal Date

RAILS(mm)
Horizontal tube

PICKET (mm)
Vertical tube

POST (mm)

CERTER
SPACE (mm)

SIZE (mm)

32*32 (0.8-2.0)
40*40*(0.8-2.0)
45*45*(0.8-2.0)
50*50*(0.8-2.0)
38*25*(0.8-2.0)

16*16*(0.8-1.5)
19*19*(0.8-1.5)
20*20*(0.8-1.5)
25*25*(0.8-1.5)
20*40*(0.8-1.5)

50*50*(1.2-2.0)
60*60*(1.2-2.0)
65*65*(1.2-2.0)
75*75*(1.2-2.0)
80*80*(1.2-2.0)

110mm
116mm
120mm
124mm
130mm

Height: 1000-2500
Width: 2950


Feature & Advantages

Due to the surface treatment of electrostatic powder spraying later stage, its high strength, high hardness, beautiful appearance, bright colour, a variety of colours, etc.
Enhanced the anti-oxidation, anti-UV, weathering and corrosion resistance property of barriers.

This kind of fencing product offers good corrosion resistance, age resistance, and beautiful view, simple and easy installation.
Low basic requirements, long service life, green environmental protection.
The price is affordable, generally measuring; it is the highest cost-effective metal wire mesh fence.

Application:

Take zinc steel as the base material, the main products are widely used in the construction fences, including balcony railing, protective window, staircase handrails, rail fences, garden fence, shutters, air conditioning fence, road fence. Industrial fences (factory fences, commercial site fences); agricultural fences (such as field fences, livestock fences); civil fences (such as building top fences, fence walls, etc.); public facilities fences (such as road isolation fences), etc.
